If you pick up a full-skirted piston from an older air-cooled engine, and measure its diameter in several places and orientations, you will see that pistons are neither round nor straight. Instead they are deliberately made oval so that their diameter is slightly greater front-to-back than it is from side-to-side (parallel with the wrist pin).
When setting piston clearance it is normal to measure diameter at the bottom of the piston skirt. But as you measure higher up, you find that the piston tapers inward slightly. And when you reach the piston ring belt close to the piston crown that is in contact with hot combustion gas that taper increases a bunch.
Sometimes its pistons would seize. Other times they broke up for no apparent reason.
Tina D.
During the power stroke, gas pressure pushes the piston downward but the angle of the connecting rod, transmitting that force to the rotating crankshaft, pushes the piston quite firmly against the rear cylinder wall. Then on compression, the resistance of the fuel-air mixture to being compressed above the piston again acts through the connecting rod, which is now angled to press the piston against the front cylinder wall.
Safe and Repeatable Passing for Trackday Riders
But there is no force at all pushing the piston against the sides of the cylinder. Even so, because of the extra mass of the wrist-pin bosses, pistons naturally expand more from side-to-side than they do back-to-front. To compensate for this, pistons are made slightly oval, measuring slightly smaller in diameter side-to-side than back-to-front.
When such pistons were heated by combustion, their crowns expanded the most, so in order to avoid seizing in the ring belt (which runs hot because it’s just below the crown) Gilera had to provide ring-belt clearance over the full length of the piston, making it very loose in the bore. If there was enough clearance to prevent seizure in the piston ring belt, the resultant clattering produced cracking and piston breakup. If the clearance were reduced to prevent that, the pistons seized.
The answer was to have its pistons made by a specialist firm that had the dedicated production equipment to make oval pistons with the necessary two-stage taper. Gilera chose Borgo, who remains in the piston business to this day.
